KEY FEATURES
– Ideal for 1/5 on road and 1/5 off road scale applications
– Incredible efficiency and low power consumption
– NMB dual main bearings
– Superior waterproof
– 15T output shaft
– 1-Year Limited Warranty
Application :
1/5 Nitro Touring 1/5 Nitro Buggy
PRODUCT SPECIFICATIONS
Type: Digital
Bearing: Dual
Motor Type: Brushless
Gear Type: Metal
Gear Material: Steel
control system: pulse width control
working frequence: 1520μs / 330hz
operating voltage: dc6.0-8.4v
operating temperature range: -10 to + 60 degree
operating speed (6.0v): 0.12 sec/60 degrees at no load
operating speed (7.4v): 0.11 sec/60 degrees at no load
operating speed (8.4v): 0.085 sec/60 degrees at no load
stall torque (6.0v): 90.0kg.cm (1249.9 oz/in)
stall torque (7.4v): 110.0kg.cm (1527.6 oz/in)
stall torque (8.4v): 125.0kg.cm (1735.9 oz/in)
potentiometer drive: direct drive
dimensions: 59.5×29.5×54.5 mm /2.34×1.16×2.15 in
weight: 209.0g (7.37 oz)
connector wire length: jr 350 mm
