*items may be in stock with supplier or via our shop stock. All items will be dispatched within 48 hours.
In stock
Designed specifically for use in model aircraft, all Radient high-torque brushless motors feature a 14 pole precision-balanced rotor, 6061-T6 aluminium alloy front and rear covers, high purity copper windings and a heavy-duty stainless steel shaft. It’s a combination that, in tandem with high-quality oversize bearings, offers beautifully smooth running, longevity and an ability to turn large propellers. With a mounting option at either end, Radient brushless outrunners are engineered to offer the flexibility and power you need over a long and trouble-free life.
| Motor Model | Watts (W) | Rec’d ESC (A) | LiPo (Cells) | Shaft Dia (mm) | Bullet (mm) | Weight (g) | Prop Sizes (Recommended) |
|---|---|---|---|---|---|---|---|
| 2822 1600KV | 180 | 20 | 2-3S | 3.0 | 3.5 | 30 | 2S: 8×4 / 9×6 | 3S: 7×4 / 8×4 |
| 2822 2300KV | 180 | 20 | 2-3S | 3.0 | 3.5 | 30 | 2S: 6×3 / 7×3.5 | 3S: 5×4 / 6×3 |
| 2826 1000KV | 220 | 20 | 2-3S | 3.0 | 3.5 | 45 | 2S: 10×6 / 11×6 | 3S: 9×6 / 10×5 |
| 2826 1300KV | 240 | 30 | 2-3S | 3.0 | 3.5 | 45 | 2S: 9×6 / 10×5 | 3S: 8×4 / 9×5 |
| 2826 1900KV | 250 | 30 | 2-3S | 3.0 | 3.5 | 45 | 2S: 8×4 / 9×5 | 3S: 7×4 / 8×4 |
| 2826 2200KV | 270 | 30 | 2-3S | 3.0 | 3.5 | 45 | 2S: 6×4 / 7×3 | 3S: 5×4 / 6×3 |
| 2830 1000KV | 260 | 30 | 2-3S | 3.0 | 3.5 | 57 | 2S: 10×6 / 11×5.5 | 3S: 9×6 / 10×5 |
| 2830 1300KV | 300 | 30 | 2-3S | 3.0 | 3.5 | 57 | 2S: 9×6 / 10×6 | 3S: 8×6 / 9×6 |
| 2836 880KV | 340 | 30 | 2-4S | 4.0 | 3.5 | 67 | 3S: 10×6 / 11×5.5 | 4S: 9×6 / 10×6 |
| 2836 1100KV | 380 | 30 | 2-4S | 4.0 | 3.5 | 67 | 3S: 9×6 / 10×6 | 4S: 8×6 / 9×6 |
| 2836 1200KV | 390 | 30 | 2-4S | 4.0 | 3.5 | 67 | 3S: 9×6 / 10×6 | 4S: 8×6 / 9×6 |
| 3530 1100KV | 310 | 50 | 2-4S | 4.0 | 3.5 | 109 | 3S: 10×6 / 11×5 | 4S: 9×6 / 10×6 |
| 3536 1050KV | 500 | 60 | 2-4S | 4.0 | 3.5 | 109 | 3S: 10×6 / 11×5 | 4S: 9×6 / 10×6 |
| 3536 1300KV | 680 | 60 | 2-4S | 4.0 | 3.5 | 109 | 3S: 9×6 / 10×6 | 4S: 8×6 / 9×5 |
| 3536 1500KV (E2K) | 750 | 80 | 2-4S | 4.0 | 3.5 | 109 | 3S: 8×6 / 9×5 | 4S: 8×4 / 8×5 |
| 3542 1000KV | 750 | 60 | 2-4S | 5.0 | 3.5 | 132 | 3S: 11×5 / 12×6 | 4S: 8×7 / 9×8 |
| 3542 1250KV | 850 | 80 | 2-4S | 5.0 | 3.5 | 132 | 3S: 9×6 / 10×5 | 4S: 8×4 / 9×5 |
| 3548 790KV | 840 | 80 | 2-4S | 5.0 | 3.5 | 172 | 3S: 11×7 / 13×6 | 4S: 9×7 / 10×8 |
| 3548 900KV | 1000 | 80 | 2-4S | 5.0 | 3.5 | 172 | 3S: 10×7 / 12×7 | 4S: 9×6 / 10×7 |
| 3548 1100KV | 1100 | 80 | 2-4S | 5.0 | 3.5 | 172 | 3S: 11×5.5 / 11×6 | 4S: 8×6 / 9×6 |
| 4250 800KV | 1250 | 80 | 2-5S | 5.0 | 4.0 | 205 | 3S: 13×6 / 14×7 | 5S: 12×8 / 13×7 |
| 4260 600KV | 1500 | 80 | 3-5S | 5.0 | 4.0 | 275 | 4S: 12×6 / 13×6 | 5S: 11×6 / 12×6 |
| 5045 720KV | 860 | 80 | 3-5S | 6.0 | 4.0 | 195 | 4S: 13×6 / 14×6 | 5S: 12×6 / 13×6 |
| 5055 570KV | 1550 | 80 | 4-6S | 6.0 | 4.0 | 275 | 4S: 14×7 / 15×6 | 6S: 13×6 / 14×5 |
| 5055 760KV | 1660 | 100 | 3-5S | 6.0 | 4.0 | 275 | 4S: 13×6 / 14×6 | 5S: 12×6 / 13×6 |
| 5065 335KV | 1660 | 100 | 4-7S | 6.0 | 4.0 | 375 | 6S: 18×8 / 19×7 | 7S: 17×7 / 18×6 |
| 5065 435KV | 1750 | 100 | 4-6S | 6.0 | 4.0 | 375 | 4S: 18×7 / 19×6 | 6S: 17×6 / 18×5 |
| 6354 200KV | 2210 | 100 | 4-10S | 8.0 | 4.0 | 480 | 8S: 19×12 / 22×12 | 10S: 18×12 / 20×10 |
“
| Weight | 0.581 kg |
|---|
Reviews
There are no reviews yet.
